Mesa de Cirugía C-Arm 840

Posicionamiento estable, accesible, preciso, silencioso y libre de vibraciones

The Surgical C-Arm Table 840 is designed for image-guided fluoroscopic procedures where stability, access, and precise, quiet, vibration-free positioning are essential. A cantilevered low attenuation carbon fiber tabletop, with choice of rectangular or contoured design, accommodates portable or ceiling-suspended C-Arms. The rectangular top offers additional space to allow for superior image quality for long-leg runoff studies. The contoured top provides ample workspace for anesthesiologists, yet the narrowness required for cervical procedures. Choose the top that best suits your needs to achieve optimum image resolution.

    • Free-Float Tabletop – With specially-designed SmoothGlide™ movement



    • Carbon-Fiber Tabletop – Low attenuation with choice of standard contoured or rectangular design



    • Contoured Tabletop – Features a face cutout for comfortable prone positioning



    • Tabletop Motion – Expansive head-to-toe, 35″



    • Radiolucent Area – Extra-large, 75″



    • Isocentric Lateral Roll – Maintains image center during tabletop movement, minimizing image distortion



    • High-Speed Actuators – Assure quick tabletop positioning, height adjustability, isocentric lateral roll and Trendelenburg motions



    • Mushroom-Shaped Control – Ergonomic, for free-float motion



    • Table Base – Encased in stainless steel, easy to clean



    • Hand and Foot-Operated Controllers – Ensure quick and safe tabletop positioning



    • Patient Capacity – 500 lb



    • Low Profile Base – For unrestricted C-arm movement



    • Accessory Rails



    • AC and Battery Power – Standard



Mesa de Braquiterapia C-Arm 810

For image-guided seed implantation

Designed and equipped specifically for seed implantation procedures, the Brachytherapy C-Arm Table features a radiolucent extension that provides capability for brachytherapy treatment involving the upper body and general C-Arm applications. Motorized actuation of height, X-Y, lateral roll and Trendelenburg motions of the tabletop, with pre-programmed features, ensure quick and safe tabletop positioning during any phase of a procedure.

The narrow Fiberesin™ tabletop of the Brachytherapy C-Arm Table is cantilevered to accommodate portable or ceiling suspended C-Arms. Radiolucent areas are free of cross members, allowing full fluoroscopic visualization and unobstructed C-Arm positioning. Optional Cassette Tray and X-ray Grid allow for use of overhead or portable x-ray. Functional design provides complete access while minimizing radiation exposure to clinicians.

  • Radiolucent Area – 54″ x 17.5″
  • Fiberesin™ Tabletop – Narrow; cantilevered to accommodate portable or ceiling suspended C-Arms
  • Fowler Positioning – Industry exclusive, 0° to 80°
  • Tabletop Positioning – Motorized, five-axis
  • Hand and Foot-Operated Controllers – For convenient positioning
  • Low Profile Base – For unrestricted C-arm movement
  • Accessory Rails
  • AC and Battery Power – Standard
