Calibradores de Dosis

soluciónes para todas las necesidades de imágenes moleculares

Atomlab™ 500Plus Dose Calibrator

The Atomlab™ 500Plus is a combination of the Atomlab™ 500 Dose Calibrator and the Atomlab™ Wipe Test Counter, together in a single unit it’s an efficient and cost-effective radioactivity measurement system.

The Atomlab 500Plus combines the industry gold standard Atomlab 500 Dose Calibrator and Wipe Test Counter, offering you a complete and cost-effective solution for all of your molecular imaging needs. The intuitive Atomlab 500Plus provides fast, accurate radionuclide activity measurements with performance that complies with the most stringent regulatory requirements. It’s comprehensive, easy-to-use and feature rich. The software mirrors the way you think and work. It guides when necessary, but does not burden the advanced user. The touchscreen and easy-to follow on-screen prompts mean you won’t need “cheat sheets.”

Automated Quality Assurance Apps:

  • Constancy and Expanded Constancy
  • Linearity and Auto Linearity
  • Accuracy
  • Geometry
  • Full Width at Half Max (FWHM)
  • Chi Square
  • Minimum Detectable Activity (MDA)

Nuclear Pharmacy Apps.

  • Future dose and volume computation
  • Half-Life Verification
  • Moly Assay
  • NEW Manual MCA Program
  • Windows® 10 Operating System
  • Microsoft SQL Database
  • Communicates with most commercially available NM management systems via Ethernet or Serial Port
  • Preprogrammed for 98 most commonly used radionuclides; any 12 can be conveniently touch selected
  • Automatic range selection; up to 100 Curies of Tc-99m or 25 Curies of F-18
  • Remote shielded ionization chamber
  • Ultra-fast response
  • Displays in Curies or Becquerels
  • 64 Channel MCA
  • NEW Manual MCA Program
  • Remote shielded well
  • Adjustable wide window and individual isotopes
  • Energy spectrums with individual ROI
  • Ability to help identify isotopes causing contamination
  • 2 x 2 NaI drilled-well detector
  • User-specific wipe locations and trigger levels
  • Wipes that exceed trigger levels are immediately recognized
  • Detailed wipe reports including cpm and dpm
  • Wipe testing results stored
  • Intuitive software with extensive functionality
  • USB connectivity for external monitor, printer, and software upgrades
  • Report and label printers available
  • Easy-to-use, touchscreen display with intuitive menus
  • Small footprint economizes workspace
  • Two-year warranty

Accesorios de Calibradores

soluciónes para todas las necesidades de imágenes moleculares

Vial/Syringe Dipper

This rugged,Vial/Syringe Dipper has a comfortable handle and it will hold 1 cc to 10 cc syringes or up to a 30 ml vial. Included with every Atomlab Dose Calibrator, the Vial/Syringe Dipper will also fit any well chamber with 2.5″ x 10″ interior dimension. The material used will not cause attenuation problems and is very resistant to breaking.


Moly Assay Shield

Moly Assay Shields are a convenient method to a unit dose. Whether working with syringes or vials, either unit will fit into the well chamber of any Atomlab Dose Calibrator.
The leaded shields are cradled by a metal holder for easy handling to ensure proper placement inside the chamber.


Dose Calibrator Shielding Rings

Especially suited for PET applications. The Dose Calibrator Shielding Ring offers an additional 2.25″ of lead shielding around the remote chamber for working with 511 keV radionuclides, such as FDG F-18. For additional protection from high energy activity.



The Lineator is a simple device to accurately and reliably verify the linearity of your dose calibrator. Test results are available in minutes, without waiting days for decay, making it feasible to perform a linearity test more often. Early identification can prevent problems before they occur.

The Lineator is a set of five tubes. Four tubes are used to perform the test and an interchangeable tube is used depending on the dynamic range needed to cover.

To perform a linearity test, insert a source of Tc-99m of the maximum activity to be measured into the central tube, then place the tube into the chamber of your dose calibrator and count. The remaining lead-lined tubes are placed, one at a time, concentrically over the central tube and counted individually or in combination. The readings are then normalized with predetermined factors, and the degree of linearity can be seen virtually at a glance.

Using only one source, the Lineator can simulate up to eight different source strengths. Each outer tube absorbs a portion of the source radiation and reduces the effective source activity seen by the dose calibrator.

PET Preparación y Envio

Compact PET Shipping Systems

«sitemas de 1, 2 y 3 unidades»
For Shipping Syringes With or Without Needles Attached.

Dose syringes fit into the pig with or without an attached needle. Designed to conserve space and minimize weight, the shipping container weighs less than 40 lb. An important feature is that the shipping container can be left at a convenient height while the pig (9 lb) can be easily removed from the container. The pig is then placed behind an L-Block Shield for dose loading and unloading. All Biodex PET L-Block Shields incorporate a hex-shaped plate that corresponds with the hex shape at the base of the pig. This design element allows one-handed loading and unloading of syringes.

High-Energy PET Sharps Container Shield

Designed to stand on, or recess into, a countertop.

The Sharps Container Shield for PET is a simple, safe and convenient solution for disposal of syringes that have been contaminated with high-energy radionuclides. The shield is constructed of steel and lined with 1″ thick (2.5 cm) lead.
The shield is designed to be used with 039-413 sharps containers. It features a lockable sliding cover for container removal and a hinged top door for syringe disposal.
The shield can stand independently or can be recessed into a cabinet or countertop.
